HP682 DMR Two-Way Radio

The Hytera HP682 is a rugged DMR handheld built for demanding workdays, with a bright color screen and a full keypad that makes it quick to find contacts, change zones, and manage calls. It delivers loud, AI-cleaned audio, includes built-in Bluetooth for wireless accessories, and provides extended battery life to help your team stay connected through full shifts.

Add to Quotes
Download Brochure

Overview Description of the Hytera HP682:

The Hytera HP682 is built for crews that require clear communication, fast access to critical data, and a device that thrives in harsh conditions. Featuring a 1.8-inch color display and a full tactile keypad, this radio is designed for users who need to manage complex talk groups and text messaging without sacrificing durability.

Professional Audio Performance

Equipped with a large front-facing speaker and cutting-edge processing, the HP682 ensures your message gets through the first time:

  • AI-Based Noise Suppression: Utilizing deep-learning algorithms, the HP682 pulls human speech out of extreme background noise in real time. It can reduce environmental distractions—like wind, sirens, or heavy machinery—by up to 30 dB.

  • Automatic Gain Control (AGC): This feature maintains a consistent volume for the listener. It automatically adjusts the microphone sensitivity to compensate for users who speak too softly or are shouting over loud noise, ensuring every transmission is balanced and easy to understand.

  • Acoustic Feedback Control: Advanced “howling” suppression prevents the ear-piercing screech that occurs when multiple radios are used in close proximity.

  • Water Porting Technology: Designed for the elements, this feature allows water to drain quickly from the speaker cavity, maintaining audio clarity immediately after exposure to rain or submersion.

Intuitive Interface & Messaging

The HP682 is designed for high-speed operation with a user-friendly layout:

  • Layered Color Interface: A 1.8-inch screen with simplified menus, clear alerts, and an “interface switcher” that allows users to jump between the screens they use most.

  • Conversational Texting: Supports text messaging with a conversational view for easy tracking of threads.

  • Tactile Keypad: Built with wear-resistant keys and navigation buttons for fast dialing of private, group, or phone calls.

Range, Reliability, and Security

  • Enhanced Coverage: High receiver sensitivity improves coverage distance and strengthens in-building penetration, keeping you connected where other radios fail.

  • Multi-Network Support: Compatible with legacy analog systems and modern digital networks, including support for ARC4 and AES encryption.

  • Elite Protection: Features radio authentication and “stun/kill” capabilities to remotely disable units if they are lost or stolen.

Tech Specs of the Hytera HP682:

  • Frequency range: UHF 400–527 MHz; VHF 136–174 MHz

  • RF power output: VHF 5W high / 1W low; UHF 4W high / 1W low

  • Channel capacity: 1,024 (512 analog, 512 digital)

  • Zone capacity: 64 zones, up to 256 channels per zone

  • Channel spacing: 12.5 / 20 / 25 kHz

  • Rated voltage: 7.7V

  • Battery: 2,000mAh lithium polymer

  • Battery life (5/5/90): 16 hours with GPS on; 20 hours with GPS disabled

  • Weight: 9.88 oz (280 g)

  • Size (H × W × D, without antenna): 122 × 55 × 31.5 mm

  • Display: 1.8-inch LCD, 160 × 128, 65,536 colors, 6 rows

  • Bluetooth: 5.0 (BLE + EDR)

  • Dust and water: IP68

  • Operating temperature: 0°F to 140°F (-20°C to 60°C)

  • Storage temperature: -40°F to 185°F (-40°C to 85°C)

  • ESD: ±8 kV contact, ±15 kV air

  • Receiver sensitivity: 0.18 μV (digital, BER 5%); 0.16 μV typical (analog, 12 dB SINAD)

  • Rated audio output: 0.5W

  • GPS (typical, on GPS models): cold start <60s; hot start <10s; accuracy <5 m

  • Optional encryption: advanced end-to-end digital encryption (license required)

Model options (common)

  • HP682-Um: UHF 400–527 MHz (antenna 400–470), 1–4W

  • HP682-V1: VHF 136–174 MHz (antenna 147–160), 1–5W

  • HP682-G-BT-Um: UHF, 1–4W, with GPS + Bluetooth

  • HP682-G-BT-V1: VHF, 1–5W, with GPS + Bluetooth

Standard accessories

BP2002: 2,000mAh lithium polymer battery, PS1014: power adapter, Standard long antenna (band-matched), RO03: nylon hand strap, BC48: belt clip, CH10L30: drop-in single unit charger

Optional accessories

Programming and charging

PC152: USB programming cable, MCL39: 6-radio multi-unit charger

Remote speaker microphones

SM26N1-P: palm PTT mic with speaker + emergency button (IP67), SM26N2-P: palm PTT mic with speaker + emergency button (IP54), SM27W2: Bluetooth remote speaker microphone (IP67)

Headsets and earpieces

ECN21-P: heavy-duty noise-cancelling headset with PTT + boom mic, ACN-02P: mic + PTT with VOX, 3.5mm jack (IP54), ES-01: receive-only earbud, EA-01: receive-only earpiece with transparent acoustic tube, EAS03: receive-only transparent acoustic tube earpiece, EH-01: receive-only C-style earloop, EH-02: receive-only swivel earpiece, EHN26-P: C-style earpiece with mic + in-line PTT, EAN24-P: transparent acoustic tube surveillance earpiece with mic + in-line PTT

Bluetooth accessories

POA121: PTT Bluetooth ring, ESW01: Bluetooth earpiece with charger, ESW08: Bluetooth earpiece with PTT button + microphone

Key Features of the Hytera HP682:

LOUDER, CLEANER AUDIO
Large forward-facing speaker plus AI voice enhancement helps separate speech from loud background sound, reducing unwanted noise by up to 30 dB.

FEEDBACK HOWLING CONTROL
Acoustic feedback suppression helps prevent squeal when multiple units operate close together.

WATER-PORTING SPEAKER DRAIN
Drains water from the speaker cavity to help maintain audio clarity after water exposure.

20-HOUR SHIFT LIFE
Lightweight lithium-polymer battery supports up to 20 hours of operation with GPS disabled, using a 5/5/90 duty cycle.

RUGGED, JOBSITE READY
IP68 and MIL-STD-810G durability. Dustproof, water-resistant, built to handle 2-meter drop shock testing. An anti-magnetic speaker helps resist metal dust and shavings.

CLEAR, BRIGHT COLOR DISPLAY + KEYPAD
1.8-inch TFT-LCD (160 × 128) with 65,536 colors, six lines of content, plus keypad and navigation keys for fast dialing and message handling.

SIMPLIFIED NAVIGATION
App-style icon layout with streamlined layers for quicker setting changes.

CLEAR NOTIFICATIONS
Home screen shows time, contact alias or ID, plus alerts like emergency calls, missed calls, call alerts, and new messages.

MULTIPLE USER PROFILES
Four profiles help match tone, volume, vibration, and other settings to the work setting, such as indoor, outdoor, or meeting.

INTERFACE SWITCHER
Quickly jump between the home screen plus up to three favorite screens for faster response.

DYNAMIC CALLING
Dial private, group, or phone calls from one place, while viewing call mode, encryption status, recording status, forwarding status, and duration.

TEXT MESSAGING WITH CONVERSATION VIEW
Send private or group messages. Use freeform typing or preprogrammed messages. Messages appear like a dialog thread for faster reading.

EXTENDED COVERAGE + CONNECTIVITY
Designed to increase coverage distance and building penetration by about 25% through improvements in transmit efficiency, receiver sensitivity, antenna gain, and reduced attenuation.

HIGH-SENSITIVITY RECEIVE
High sensitivity helps improve usable range in weak-signal areas.

GPS LOCATION TRACKING (ON GPS MODELS)
Share real-time location with other units, dispatch, or third-party apps. GPS can transmit during calls. Compression can reduce channel load.

HIGHER SECURITY OPTIONS
Digital end-to-end plus over-the-air encryption options using ARC4 or AES. Authentication helps block unauthorized access. Stun or kill can disable lost units.

BLUETOOTH BUILT IN
Bluetooth supports wireless audio accessories and data features.

MULTI-SYSTEM OPERATION
Works across multiple analog and digital networks, including conventional, trunking, IP multi-site connect, and simulcast systems.

DTMF SIGNALING
Manual DTMF dialing with the keypad, plus up to 256 stored DTMF strings for quick use.

SILENT VIBRATE MODE
Vibrate alerts help in quiet settings.

Hytera HP682 FAQs

What is the Hytera HP682, and what kind of systems can it run on?

This is an H-Series handheld built for DMR use. It can work across many network types, including analog and digital conventional, plus options like XPT trunking, DMR Tier II trunking, IP Multi-Site Connect, and DMR simulcast setups.

How clear is the audio in loud places?

It uses AI noise suppression to cut background sound in real time. It also has feedback control to help stop “howling” when units are close, and a water-draining speaker design to keep sound clear after rain or splashes.

How tough is this handheld for job sites?

It is rated IP67 and meets MIL-STD-810G. Hytera also lists 2-meter drop testing and an anti-magnetic speaker design to help in areas with metal dust or shavings.

How long does the battery last, and is it easy to carry all day?

It uses a lithium polymer pack and is listed for a 20-hour shift life on a 5/5/90 duty cycle. Hytera also describes a thin build that weighs under 10 ounces.

Does it have GPS tracking and Bluetooth support?

Yes. GPS can report location to other units, a dispatcher, or third-party tools in real time. Built-in Bluetooth supports audio and data, so it can pair with wireless accessories.

How does the HP682 help protect private calls and data?

It supports digital end-to-end and over-the-air encryption. Hytera lists ARC4 and AES options, plus radio authentication and remote “stun/kill” controls if a unit is lost or taken.
